Beetles taking off!

Dung beetle (Trypocopris [=Geotrupes] pyrenaeus var. coruscans) shining in the sun. Galicia, Spain
These beautiful dung beetles are relatively common in NW Spain, and can often be seen flying purposefully through the pine forests, like tiny green helicopters, on a mission to find a cow pat or some horse droppings. They are a variety of Dor beetle,  (Trypocopris pyrenaeus var. coruscans), similar to a couple of Dumble Dor beetles we have in the UK, but with a much more metallic, coppery-green sheen, which changes colour as the sun catches the iridescent cuticle. No apologies for blogging about this beetle of again, as it is one of my favourite insects, and continues to fascinate me!

Dung beetle (Trypocopris [=Geotrupes] pyrenaeus var. coruscans) in horse dung.
These beetles are active fliers; they need to find new sources of food (cow or horse dung) which they roll into balls (see below) and manoeuvre back to burrows they have dug in the ground. Presumably, they have an excellent sense of smell and fly upwind towards fresh sources of dung?

Dung beetle (Trypocopris [=Geotrupes] pyrenaeus var. coruscans) rolling in horse dung. Galicia, Spain
In Galicia, in NW Spain, there are many horses and cows on the hillsides, and the Galician ponies wander among the pine forests and heather moorlands, where this dung beetle seems to be, thank goodness, present in good numbers. It would, as I have mentioned before, make an excellent insect to study in terms of its ecology (especially in relation to traditional grazing methods), commensals (phoretic mites), iridescent colouration, impact of ivermectins (pesticide treatments for cow parasites), effects of climate change, and so on. Particularly, because it is so abundant and easy to find in the summer. Just find the dung!

Galician ponies under the trees. Galicia, Spain

On their travels in search of new dung, these beetles seem to land and take off quite a few times. They are relatively tolerant of being photographed (!), but after a few moments, seem to tire of the attentions of a large hominid, and spread their wings and take flight! I managed to catch some of the different stages of the elytra-opening and wing-unfolding process in different individuals.

Dung beetle (Trypocopris [=Geotrupes] pyrenaeus var. coruscans) about to take off, wings spread
The wings (hind wings really) are stored, folded up under the wing cases, called elytra. These hard wing cases protect the more delicate wings whilst the beetles are on the ground, feeding or pushing their way through dung in this case! Wings do not unfold instantly of course! Here is one (below) just starting to open its elytra.

Dung beetle (Trypocopris [=Geotrupes] pyrenaeus var. coruscans) elytra beginning to open its elytra
The initial stages of opening the wing cases are relatively slow, and there is a slight delay as the wings are extended, but once the wings are wide open and expanded, the beetle takes flight almost immediately.

Dung beetle (Trypocopris [=Geotrupes] pyrenaeus var. coruscans) wing cases wide open, wings starting to unfold
There are no muscles in the wing itself, and the extension of the hind wings of beetles probably occurs as a result of the hydraulic pressure of blood (haemolymph), being pumped into veins in the wings. The system of unfolding (and folding) is highly complex, with folding occurring along flexion lines. The extension of the wing also involves contraction of muscles at the base of the wing, located in the thorax, together with an increase of blood pressure (Sun et al., 2014). When the wings are folded away, they occupy a much smaller area than when open and extended of course. I think these beetles take off without jumping off the ground!

Dung beetle (Trypocopris [=Geotrupes] pyrenaeus var. var. coruscans) wing cases open, wings spread and ready to go!
In conclusion, deploying wings in beetles and other insects is a remarkable engineering feat and has been the focus of many detailed studies. Understanding how insects such as this fold and unfold their wings, from a single point at the base of the wing, could provide many useful solutions to engineering problems. In the words of one researcher:

“the hind wings of the Coleoptera are an example of a smart structure: a remote motor, stiff plates and elastic rods create a defined and repeatable movement” (Haas, 2000).

On a final note, these beetles are I believe, at risk of poisoning from ivermectins, veterinary pharmaceuticals given to cows to treat roundworms and other stomach parasites. I was very alarmed to come across a whole group of dead or dying beetles, all lying on the ground not far from each other (below). There was no dung in the vicinity; it was as though they all succumbed at the same time. The fact that not all of them were dead, and some were moribund and still twitching, made me suspect poisoning. Very worrying and something I plan to investigate further.

Dead or moribund beetles, covered in sminthurid collembola. Galicia, Spain


References and further reading

Haas, F. (2000). Wing folding in insects: A natural, deployable structure. In IUTAM-IASS Symposium on Deployable Structures: Theory and Applications (pp. 137-142). Springer, Dordrecht.

Sun, J., Ling, M., Wu, W., Bhushan, B., & Tong, J. (2014). The hydraulic mechanism of the unfolding of hind wings in Dorcus titanus platymelus (order: Coleoptera). International journal of molecular sciences15(4), 6009-6018.
